Attritor Mill Machine Manufacturer

MachineValley's Attritor Mill grinds and disperses using agitated ball media, getting particles down to size faster than a standard mill. No pre-mixing is needed, cleanup is quick, and it runs quietly enough that operators don't dread being near it. Maintenance costs stay low, even after a year of steady use.

MachineValley's Attritor Mill Machine uses agitated Ball/Bead media to grind and disperse, and it does it faster than most conventional mills on the floor. That shorter cycle time adds up over a shift, meaning more batches through the line without any drop in fineness or consistency.

Skip pre-mixing altogether for Paint and coatings plants and other applications. Cleaning between batches doesn't delay, and the machine runs quieter than you'd expect from something doing this much grinding work. The compact footprint means you're not pouring a new foundation just to fit it on the floor, and setup is straightforward enough that most plants have it running within days.

So do ink, pigment, adhesive, resin, pharma, and ceramics operations- basically anywhere fine particle size and even dispersion matter to the end product. Maintenance costs stay reasonable over the life of the machine, which is usually what people notice a year or two in, once it's just the mill doing its job in the background.

ATTRITOR MILL	AT-100	AT-200	AT-500
WORKING CAPACITY (LTR)	100	200	500
SS SHELL THICKNESS	4MM	6MM	8MM
SHAFT DIAMETER (MM)	45MM	50MM	65MM
CROSS ROD (MM)	20MM	25MM	25MM
MOTOR POWER (HP)	5HP	10HP	15HP
MOTOR RPM	0~1440	0~1440	0~1440
MS JACKET	4MM	6MM	8MM
WATER INLET OR OUTLET	1'/2' SOCKET	1'/2' SOCKET	1'/2' SOCKET
OUTLET HANDLE VALVE	50MM	50MM	75MM

ATTRITOR MILL

AT-100

AT-200

AT-500

WORKING CAPACITY (LTR)

100

200

500

SS SHELL THICKNESS

4MM

6MM

8MM
