MachineValley's High Shearing Mixing Reactor runs two agitators at once. A high-speed rotor spins inside a stator, and that's where the actual shearing happens: friction and collision break the material down. Meanwhile, a slower anchor arm with triangular blades scrapes the kettle wall so nothing cakes on the sides, wetting the powder as it goes instead of letting it clump at the bottom.
| Model11 | Emulsifier (kW) | Emulsifier Speed (rpm) | Anchor (kW) | Anchor Speed (rpm) | Batch Size | Usable Volume (max.) |
|---|---|---|---|---|---|---|
| MVHS1000 | 11 | 0–2880 | 0–2880 | 55 | 1000 kg | 800 L |
| MVHS2000 | 18.5 | 0–1450 | 4 | 50 | 2000 kg | 1600 L |
| MVHS3000 | 22 | 0–1450 | 5.5 | 35 | 3000 kg | 2400 L |
| MVHS4000 | 30 | 0–1450 | 7.5 | 35 | 4000 kg | 3200 L |
| MVHS5000 | 37 | 0–1450 | 11 | 35 | 5000 kg | 3900 L |
500 Liter High Shear Mixing Reactor
Compact capacity suited for small-batch or R&D-scale agrochemical SC production. Delivers the same rotor-stator shear and anchor scraping action as larger models, ideal for trial runs and formulation development.
1000 Liter High Shear Mixing Reactor
Matches the entry production capacity, suited for manufacturers stepping up from lab-scale to regular batch production while keeping floor space compact.
2000 Liter High Shear Mixing Reactor
A mid-range capacity for manufacturers running consistent production volumes, balancing throughput with a manageable plant footprint.
5000 Liter High Shear Mixing Reactor
Built for high-volume agrochemical SC production lines, matching the top end of the current lineup for manufacturers needing large, continuous batch output.
